| Display | |
|---|---|
| Size | 5" |
| Panel Type | LCD |
| General | |
| Dimensions | 19 x 8.94 x 3.48" / 48.3 x 22.71 x 8.84 cm |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 140°F / -20 to 60°C up to 90% Humidity |
| Compatibility | Not Specified by Manufacturer |
| Supported Operating Systems | macOS 14.0 Sonoma, 15.0 Sequoia, 26.0 Tahoe or Later Windows 10 and 11, Windows 11 for ARM |
| Buttons | 42 x Backlit LED 8 x Source 4 x Transition 6 x Talkback and Mix |
| Codecs Supported | SMPTE 2110 IP Blackmagic IP10 Optional for 2160p59.94 and 2160p60 |
| Power | |
| Power Source | Plug-In Power |
| Standards | |
| Video Standard Compliance | SMPTE 2110‑20, SMPTE 2110‑21, SMPTE 2110‑30, SMPTE 2110‑40, SMPTE 2022‑7 |
| Video Capture | |
| Supported Protocols | IEEE 1588-2008 (PTP v2) ST 2059-1 ST 2059-2 NMOS |
| Specs | |
| Color | 10-Bit, 4:2:2 |
| USB I/O | 1 x USB-C (Firmware Only) Female Input |
| Mounting | 2x Rack Ears |
| Video Formats | UHD 4K 3840 x 2160p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 HD 1920 x 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 HD 1920 x 1080i: 60, 59.94, 50 1280 x 720p: 60, 59.94, 50 |
| Power Input | 2 x IEC C14 (Redundant) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Surface | |
| Touchscreen | No |
| Interface | |
| Video I/O | 2x RJ45 Input ( Redundant 10G LAN Connections ) 2x BNC (12G-SDI) Monitor Output ( Program, Preview, Multiview ) 1x HDMI 2.0 Monitor Output ( Multiview ) |
| Audio I/O | 1x XLR 5-Pin Headphone/Mic Input/Output (Talkback) |
| Other I/O | 1 x RJ45, 1G Ethernet Control |
| Others | |
| Marka | Blackmagic Design |
| Rack Units | 2 RU |
| Color Spaces | Rec. 709, Rec. 2020 |
| Software | ATEM Setup Utility ATEM Software Control Panel |
