| Connectivity | |
|---|---|
| Analog Outputs | 2x 1/4" TRS Balanced/Unbalanced Aux Send 2x 1/4" TRS Balanced/Unbalanced Stereo Main Output (1 Stereo Pair) 1x 1/4" TRS Unbalanced Stereo Headphone Output |
| USB I/O Capacity | 12x Input / 4x Output |
| Expansion Ports | No |
| External Display I/O | No |
| General | |
| Dimensions | 8.8 x 1.8 x 4.5" / 22.3 x 4.6 x 11.4 cm |
| Weight | 1.3 lb / 0.6 kg |
| Meters | Main Meter: 2x 6-Segment LED |
| Packaging Info | |
| Package Weight | 1.815 lb |
| Box Dimensions (LxWxH) | 11.6 x 6.4 x 2.9" |
| Performance | |
| Headphone Output Power | 50 mW per Channel into 63 Ohms (Max) |
| Max Input Level | Combo XLR-1/4" Mic/Line Input: +4 dB (Mic) +24 dB (Line) 1/4" TS Line Input: +9 dB |
| I/O Impedance | XLR Line/Mic Input: 3.8 Kilohms 1/4" TRS Line Input: 39 Kilohms 1/4" TRS Aux/Main Output: 147 Ohms 1/4" TRS Monitor Output: 14.7 Ohms |
| Signal Generator | No |
| Control | |
| Presets | 3x Scene |
| Mixer | |
| Max I/O Capacity | 6x Input / 6x Output |
| Number of Analog Output Channels | 4 |
| Mix Routing | 2x Mono Aux Send 1x Stereo Main LRC |
| Faders & Level Adjustment | 6 Channel Knob |
| Specs | |
| USB I/O | 1x USB-C 2.0 (Host Connection) |
| Number of Analog Input Channels | 6 (2 Mono / 4 Stereo) |
| Wireless | No |
| Number of Mic Preamps | 2 |
| Frequency Response | 20 Hz to 20 kHz -1 dB |
| Rack Mountable | Yes |
| EQ | 3-Band EQ |
| Sample Rates | 48 kHz |
| Phantom Power | +48 V |
| MIDI I/O | No |
| Analog Inputs | 2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input 8x 1/4" TS Balanced/Unbalanced Line Input (4 Stereo Pairs) |
| Solo/Mute | Mute per Input Channel |
| Electrical | |
| Input Power | 5 VDC |
| Recording | |
| Max Multitrack Recording | 12 Tracks |
| Bit Depth | Up to 32-Bit |
| Media Support | SDHC |
| Interface | |
| Digital I/O | No |
| Signal Processing | |
| Built-In Effects | 5x Stereo Effect (Type Unspecified) |
| EQ Parameters | 1x HF Shelf: ±15 dB at 10 kHz 1x MF Peak: ±15 dB at 100 Hz to 8 kHz 1x LF Shelf: ±15 dB at 100 Hz |
| Graphic EQ | No |
| Audio Delay | No |
| Automatic Mic Mixing | No |
| Others | |
| Marka | Zoom |
Fiyat:
23.350,08 ₺
