| General | |
|---|---|
| Dimensions | With Iso-Pod: 17.8 x 11.3 x 10.9" (452 x 286 x 278 mm) Without Iso-Pod: 17.1 x 11.3 x 10.9" (433 x 286 x 278 mm) |
| Weight | 28 lb (12.7 kg) |
| Enclosure Material | Die-cast aluminum |
| Voltage Range | ±10% |
| Packaging Info | |
| Package Weight | 36.35 lb |
| Box Dimensions (LxWxH) | 16.5 x 15.5 x 15.4" |
| Physical | |
| Mounting Options | Tabletop (with included Iso-Pod) Four 0.24 x 0.39" (6 x 10 mm) threaded holes for Omnimount Series 60 brackets and K&M loudspeaker mounts |
| Power | |
| Power Consumption | Idle: 10W Standby: <0.5W Full Output: 170W |
| Specs | |
| Controls | Sensitivity Adjustment Dial Power Switch Tone Controls: Treble Tilt (Off, -2 dB, -4dB, +2 dB @ 15 kHz) Bass Tilt (Off, -2 dB, -4 dB, -6 dB @ 100 Hz) Bass Roll-Off (Off, -2 dB, -4 dB, -6 dB @ 35 Hz) Desktop Control (-4 dB @ 160 Hz) |
| Inputs | 1x XLR balanced |
| Frequency Response | 38 Hz to 20 kHz (± 2 dB) 35 Hz to 21 kHz (-3 dB) |
| Maximum SPL | 110 dB |
| Crossover Frequency | 3.0 kHz |
| Others | |
| Marka | Genelec |
| Low Frequency Driver | 8" (205 mm) |
| High Frequency Driver | 1" (25 mm) metal dome |
| LF Amplifier | 150W |
| HF Amplifier | 120W |
| Power Supply (AC) | 120V |
