| General | |
|---|---|
| Display | Single-LED Indicators Only |
| Gain Range | -3 to +42 dB (3 dB Steps) |
| Packaging Info | |
| Package Weight | 6.025 lb |
| Box Dimensions (LxWxH) | 16.1 x 13.8 x 3.1" |
| Physical | |
| Cable Length | 5' / 1.6 m |
| Mounting Options | Rackmount (with Included Hardware, 1 U Half-Rack) |
| Power | |
| Transmitter Battery Type | 2x AA (Included) or 1x Sennheiser Battery Pack (Not Included) |
| Included Charging Case | No |
| AC/DC Power Adapter | 11 to 13 VDC at 300 mA (Included) |
| Transmitter Battery Life | 8 Hours (Alkaline) 12 Hours (Sennheiser Battery Pack) |
| System | |
| Wireless Technology | Digital UHF |
| Diversity | Yes |
| RF Frequency Band | 470 to 526 MHz |
| Max Operating Range | 328.1' / 100 m (Line of Sight) |
| Number of RF Channel Frequencies | 2240 |
| Max Transmitters per Band | 90 |
| Built-In Recorder | No |
| Specs | |
| Color | Black |
| Microphone Type | 1x Headset |
| Power Requirements | AC/DC Power Adapter |
| Environmental Resistance | No |
| Mobile App Compatible | No |
| Input Level | Microphone / Line / Instrument |
| Polar Pattern | Cardioid |
| Latency | 1.9 ms |
| Frequency Response | 20 Hz to 20 kHz ±3 dB |
| Network I/O | No |
| Dynamic Range | 134 dB |
| Output Connector | 1x 1/8" / 3.5 mm Locking TRS Male |
| Electrical | |
| Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Security | |
| Encryption | No |
| Interface | |
| Audio I/O | 1x XLR 3-Pin Balanced Output 1x 1/4" TS Unbalanced Output |
| Receiver | |
| Receiver Type | 1x Tabletop/Rack-Mountable |
| Number of Audio Channels | 1 |
| Word Clock I/O | No |
| Transmitters | |
| Included Transmitters | 1x Bodypack |
| RF Output Power | 10 mW ≤ 10 mW |
| Antenna | 2x Removable BNC External (Rear-Mount) |
| Auto-Level/Gain | No |
| Muting | Mute Switch |
| Sync Method | Bluetooth |
| Others | |
| Marka | Sennheiser |
| Bias/Plug-In & Phantom Power | 2 to 4.35 V Bias/Plug-In Power No Phantom Support |
