| Display | |
|---|---|
| Panel Type | IPS-Type LCD |
| Native Resolution | 1920 x 1080 |
| Display Size | 19.00" / 48.26 cm |
| Aspect Ratio | 16:9 |
| Maximum Brightness | 1200 nits / cd/m2 |
| HDR Support | Yes: Hybrid Log Gamma |
| Color Gamut | 100% DCI-P3 |
| Color Support | 1.07 Billion Colors (8-Bit+FRC) |
| LUT Support | Yes |
| Image Controls | Anamorphic De-Squeeze, False Color, Focus Peaking, OSD Flip, Pixel Zoom, RGB Parade, Vectorscope, Waveform, Zebra |
| General | |
| Dimensions | 19.8 x 13 x 7.1" / 504 x 330 x 180 mm (Including Feet) 19.8 x 12.2 x 2.5" / 504 x 310 x 63 mm (Excluding Feet) |
| Weight | 12.02 lb / 5.45 kg |
| VESA Mounting-Hole Pattern | 100 x 100 mm |
| Built-In Speaker | Stereo |
| Packaging Info | |
| Package Weight | 21.3 lb |
| Box Dimensions (LxWxH) | 24 x 15.25 x 7.25" |
| Power | |
| Power Consumption | 75 W |
| Power I/O | 2x XLR 4-Pin (14.4 VDC) Input 1x XLR 4-Pin (16.8 VDC) Input |
| Format Support | |
| Video Format | HDMI/SDI (10-Bit 4:2:2) DCI 4K: 60 UHD 4K: 60 |
| Embedded Audio | HDMI: 8-Channel SDI: 12-Channel |
| Video Signal Conversion | HDMI to SDI SDI to HDMI |
| Wireless | |
| Wi-Fi | No |
| Bluetooth | No |
| System | |
| Timecode Support | Yes |
| Specs | |
| Media/Memory Card Slot | Single Slot: SSDmini/SSD with Master Caddy II/III [Supports Recording] |
| Material of Construction | Aluminum, Polycarbonate |
| Wireless | No |
| Mobile App Compatible | No |
| Reference Input | No |
| Battery | Interchangeable Mount (No Plate Included) |
| Phantom Power | +48 V |
| Surface | |
| Touchscreen | Yes |
| Electrical | |
| Input Power | 12 to 16.8 VDC |
| Mounting | |
| Tripod/Accessory Mounting | 10x 1/4"-20 Female 5x 3/8"-16 Female |
| Recording | |
| Pulldown Conversion | 2:2, 3:2 |
| Pre-Roll Record | Full HD: 8 Seconds 4K: 2 Seconds |
| Camera Trigger | SDI, HDMI |
| Encoding Formats | x ProRes Raw ProRes 422 HQ 10-Bit DNxHR 422 HQ 10-Bit |
| Interface | |
| Video I/O | 1x HDMI 2.0 Input 1x HDMI 2.0 Output 2x BNC (12G-SDI) Input 2x BNC (3G-SDI) Input 1x BNC (12G-SDI) Loop Output |
| Audio I/O | 2x XLR Input 2x XLR Output 1x 1/8" / 3.5 mm Headphone Output |
| Other I/O | 1x BNC (Genlock) Input 1x 2.5 mm (LANC) Input |
| Others | |
| Marka | Atomos |
| Closed Caption Support | No |
Fiyat:
168.364,80 ₺
3500 TL üzeri alışverişlerde kargo bedava
