| Connectivity | |
|---|---|
| HDCP Support | No |
| General | |
| Dimensions | 3.3 x 2.4 x 1" / 83.82 x 60.96 x 25.4 mm |
| Weight | 0.3 lb / 0.14 kg |
| Operating Conditions | 32 to 104°F / 0 to 40°C at 10 to 90% Humidity |
| Storage Conditions | -40 to 284°F / -40 to 140°C |
| Packaging Info | |
| Package Weight | 0.65 lb |
| Box Dimensions (LxWxH) | 7.25 x 5.5 x 4.05" |
| Physical | |
| Certifications | BSMI CNS 13438 Class A, CE, FCC Part 15 Class A, FCC, ICES, VCCI Class A |
| Power | |
| Power Consumption | 4 W |
| Power I/O | 1x USB-B Input |
| Format Support | |
| Video Resolution | SDI Input (10-Bit 4:2:2 YCC),1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps,1920 x 1080i at 50/59.94/60 fps,1280 x 720 at 50/59.94/60 fps,USB-B Output,1920 x 1080p at 15/25/29.97/30/50/59.94/60 fps,1440 x 1080p at 15/25/29.97/30/50/59.94/60 fps,1280 x 720 at 15/25/29.97/30/50/59.94/60 fps,1024 x 576 at 15/25/29.97/30/59.94/60 fps,960 x 540 at 15/25/29.97/30/50/59.94/60 fps,856 x 480p at 15/25/29.97/30/50/59.94/60 fps,800 x 600 at 15/25/29.97/30/50/59.94/60 fps,768 x 576p at 15/25/29.97/30/50/59.94/60 fps,720 x 576p at 15/25/29.97/30/50/59.94/60 fps,720 x 480p at 15/25/29.97/30/50/59.94/60 fps,640 x 480p at 15/25/29.97/30/50/59.94/60 fps,640 x 360 at 15/25/29.97/30/50/59.94/60 fps,352 x 288 at 15/25/29.97/30/50/59.94/60 fps,320 x 240 at 15/25/29.97/30/50/59.94/60 fps |
| Embedded Audio | SDI: 2-Channel |
| Audio Format | Analog Input: 48 kHz / 24-Bit,Analog Output: 48 kHz / 16-Bit |
| Standards | |
| Broadcast System Compatibility | NTSC |
| External Enclosure | |
| System Connection | USB-B 3.0 / 3.1/3.2 Gen 1 |
| Specs | |
| Reclocking | No |
| Software | |
| OS Compatibility | Windows 11,macOS 12.3,Linux 20 |
| Interface | |
| Video I/O | Input,1x BNC (3G-SDI) Female,Output,1x BNC (3G-SDI) Female (Loop Output) |
| Audio I/O | No |
| Others | |
| Marka | AJA |
Fiyat:
22.133,93 ₺
3500 TL üzeri alışverişlerde kargo bedava
