| Display | |
|---|---|
| Display Size | 2.2" |
| Connectivity | |
| HDCP Support | No |
| General | |
| Dimensions | 11 x 6.94 x 1.74" / 27.9 x 17.63 x 4.42 cm |
| Weight | 4.13 lb / 1.87 kg |
| Operating Conditions | 32 to 72°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 140°F / -20 to 60°C |
| Rack Form Factor | 1 U |
| Packaging Info | |
| Package Weight | 4.81 lb |
| Box Dimensions (LxWxH) | 13.4 x 8.6 x 3.5" |
| Power | |
| Power Consumption | Device: 36 W |
| Power I/O | 1x IEC C14 Input |
| Standards | |
| Video Standard Compliance | SMPTE 292M/296M/424M/425M-A/425M-B |
| IP Encoding/Decoding | |
| IP Video | 1280 x 720 to 1920 x 1080 Encoding |
| Processing | |
| Switching Type | Pushbutton, Software |
| Processing Resolution | 1080p |
| Color Processing | 10-Bit 4:2:2 |
| Mix Effects | |
| Available M/E Layers | 1 M/E |
| Effect Types | 4x Chroma Key 5x Luma Key 1x DVE, Stinger |
| Downstream Keys | 1x Chroma, Luma, DVE |
| Generators | 2x Color 5x Pattern |
| Audio Mixing | 28-Channel Mixing |
| Computing | |
| Processor | Not Specified by Manufacturer |
| Specs | |
| Wireless | No |
| Input | |
| Video Inputs | 10x BNC (3G-SDI) |
| Number of Video Input Sources | 10 |
| Input Video Format | SDI (10-Bit 4:2:2) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps |
| Audio Inputs | 2x 1/4" TRS Stereo Analog Female |
| Input Audio Format | Analog |
| Software | |
| OS Compatibility | macOS 11.1 or Later / Windows 10 or Later |
| Interface | |
| Other I/O | 1x BNC Blackburst, Reference, Tri-Level Sync Input 1x RJ45 Control 1x RJ45 Talkback Input/Output 1x XLR 5-Pin Talkback Input/Output |
| Output | |
| Video Outputs | 6x BNC (3G-SDI) 1x USB-C (USB Video) (Program) |
| Video Output Channels | 6 |
| Output Video Format | SDI (10-Bit 4:2:2) 1080p at 23.98/24/25/29.97/30/50/60 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps |
| Embedded Audio Output | SDI USB-C |
| Multiview Output | 16-Way Multiview via SDI |
| Diğer | |
| Marka | Blackmagic Design |
Anlaşmalı tüm kredi kartlarında
| Taksit | Aylık Ödeme | Toplam Tutar |
|---|---|---|
| Tek Çekim | 81.980,10 ₺ | 81.980,10 ₺ |
| 2 Taksit | 42.738,04 ₺ | 85.476,07 ₺ |
| 3 Taksit | 29.117,42 ₺ | 87.352,26 ₺ |
| 6 Taksit | 15.750,26 ₺ | 94.501,56 ₺ |
| 9 Taksit | 11.583,04 ₺ | 104.247,33 ₺ |
| 12 Taksit | 9.835,41 ₺ | 118.024,91 ₺ |
Tutarlara KDV dahildir. Taksit seçenekleri kartınızın bankasına göre ödeme adımında kesinleşir.
