| Connectivity | |
|---|---|
| HDCP Support | Yes: Version 1.4 |
| General | |
| Dimensions | 3.9 x 3.1 x 0.9" / 100 x 80 x 24 mm |
| Weight | 9.6 oz / 272 g |
| Operating Conditions | -4 to 113°F / -20 to 45°C |
| Storage Conditions | -4 to 158°F / -20 to 70°C |
| Display | LCD |
| Packaging Info | |
| Package Weight | 1.405 lb |
| Box Dimensions (LxWxH) | 7.5 x 6.1 x 3.4" |
| Power | |
| Power Consumption | 6 W |
| Power I/O | 1x Barrel (5 to 18 VDC ) Input |
| PoE Support | Yes: PoE 802.3af |
| Format Support | |
| Embedded Audio | HDMI/NDI |
| IP Encoding/Decoding | |
| IP Video | Encoding/Decoding via H.264 1920 x 1080 (90.00 to 125 Mb/s) |
| Transport Protocols | NDI/HX |
| Specs | |
| Wireless | No |
| Reclocking | No |
| Interface | |
| Video I/O | Input/Output 1x RJ45 (NDI) Female Input 1x HDMI Female Output 1x HDMI Female |
| Audio I/O | Input 2x 1/8" / 3.5 mm TRS Output 1x 1/8" / 3.5 mm TRS |
| Other I/O | Input/Output 1x DisplayPort 3.0 / 3.1/3.2 Gen 1 |
| Others | |
| Marka | Kiloview |
