| General | |
|---|---|
| Dimensions | 5.9 x 6.3 x 2.4" / 15.0 x 16.0 x 6.0 cm |
| Weight | 6 lb / 2.6 kg (With Lens Mount Adapter) |
| Operating Conditions | -4 to 113°F / -20 to 45°C |
| Storage Conditions | -22 to 158°F / -30 to 70°C |
| Item Type | 1x Handgrip for Top Side |
| Materials | Aluminum, Rubber, Steel |
| Inputs/Outputs | 1x Proprietary (34 VDC) Input 2x Reversible D-Tap Output 2x LEMO 2-Pin (13 VDC) Output 1x LEMO 2-Pin Output 2x LEMO 3-Pin Output 1x Hirose 4-Pin (5 to 13 VDC) Output 2x USB-A (5 VDC / 1 A) Output |
| Compatibility | ARRI ALEXA Mini / ALEXA Mini LF |
| Interface | PCIe (Unspecified Type) |
| Lens Mount | Interchangeable Mount with Included ARRI LPL |
| Plate Front / Battery Mount | Gold Mount |
| Support Type | Shoulder Support |
| Accessory Mounting Thread | 5x 3/8"-16 |
| Rotation | No |
| Main Attachment | 4x Unspecified Male Screw (Included) Camera Compatibility ARRI ALEXA M ARRI ALEXA Mini ARRI AMIRA |
| Camera Compatibility | ARRI ALEXA Mini, ARRI ALEXA Mini LF |
| Accessory Mounting | 1x ARRI Anti-Twist 3/8"-16 Female Thread 2x Anti-Twist 1/4"-20 Female Thread |
| Grip Type | No |
| Netflix Approved | Yes |
| Image Stabilization | No |
| Hot-Swap Support | No |
| Maximum Write Speed | 16,000 MB/s |
| Packaging Info | |
| Package Weight | 0.775 lb |
| Box Dimensions (LxWxH) | 19.9 x 16.2 x 15.8" |
| Power | |
| Power Consumption | ≥65 W |
| Power I/O | 1x LEMO 8-Pin (10.5 to 34VDC) Input 1x RS 3-Pin (24VDC) Output 1x LEMO 2-Pin (12VDC) Output 1x Proprietary (24VDC) Output |
| Drives | |
| Storage Capacity | 2 TB |
| Imaging | |
| Image Sensor | 36.7 x 25.54 mm (ARRI Large Format) CMOS |
| Effective Sensor Resolution | 13 Megapixel (4448 x 3096) |
| Lens Communication | Yes: Cooke /i, ARRI LDS, ARRI LDS-2 |
| Built-In ND Filter | Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters |
| Capture Type | Video Only |
| Internal Filter Holder | No |
| Video Capture | |
| Internal Recording | ARRIRAW/MXF/ARRIRAW 4448 x 3096 up to 40 fps 2880 x 2880 up to 60.00 fps* 3424 x 2202 up to 60.00 fps* 3840 x 2160 up to 60.00 fps* 4448 x 1856 up to 60.00 fps MXF/ProRes/ProRes 422/ProRes 422 HQ/ProRes 4444/ProRes 4444XQ 4448 x 3096 up to 40 fps 2880 x 2880 up to 60.00 fps* 3840 x 2160 up to 48.00 fps* 2880 x 2160 up to 75 fps* 4448 x 1856 up to 60.00 fps* 3200 x 1800 up to 75 fps* 1920 x 1080p up to 75/100 fps* *Sensor Crops During Recording |
| Fast-/Slow-Motion Support | Yes |
| Audio Recording | MXF: 2-Channel, 24-Bit at 48 kHz via LPCM Audio |
| Gamma Curve | ARRI Log C, Rec709, Rec2020 |
| Charger | |
| Indicator | No |
| Battery Charger | |
| Number of Battery Bays | 1 |
| Specs | |
| Media/Memory Card Slot | Slot 1: Codex Compact Drive |
| Material of Construction | Aluminum Alloy |
| Sensor Resolution | 13 Megapixel (4448 x 3096) |
| Wireless | Wi-Fi |
| Mobile App Compatible | No |
| Rod Standard | 19 mm Studio / 104 mm Spacing |
| Additional Mounting | Multiple 1/4"-20 Female Thread Multiple 3/8"-16 Female Thread |
| Mounting Threads | Multiple: 3/8"-16, 1/4"-20 |
| Max Recording Modes | ARRIRAW/MXF/ARRIRAW Up to 4.4K up to 40 fps MXF/ProRes/ProRes 422/ProRes 422 HQ/ProRes 4444/ProRes 4444XQ Up to 4.4K up to 40 fps |
| Rod Ports | 2x 15 mm Rod Port |
| Built-In Microphone | Stereo |
| Power & I/O | |
| Battery Plate Type | No |
| Mounting | |
| Shoe Mounting | No |
| Rosettes | 2x ARRI Rosette w/ M6 Female Thread |
| Cable Clamp | No |
| Exposure Control | |
| Shutter Type | Electronic Rolling Shutter |
| ISO/Gain Sensitivity | Native: 160 to 3200 |
| Shutter Speed | 1/8000 to 1 Second |
| White Balance | Range: 2000 to 11,000K Presets: Auto, Color Temperature, Manual |
| Shutter Angle | 5 to 356° |
| Advertised Dynamic Range | 14 Stops |
| Interface | |
| Internal Storage | No |
| Video I/O | 2x BNC (6G-SDI) Output |
| Audio I/O | 1x 6-Pin LEMO Input |
| Other I/O | 1x LEMO 5-Pin (Timecode) Data Input/Output 1x LEMO 10-Pin (LAN) Control/Data Input/Output 1x BNC (Sync) Control Input 1x LEMO 7-Pin Monitor/Video Input/Output 1x USB-A (USB 2.0) Data 1x Proprietary Viewfinder |
| Global Positioning (GPS, GLONASS, etc.) | No |
| Focus | |
| Focus Mode | Automatic, Manual Focus |
| Viewfinder | |
| Type | Optional, Not Included |
| Others | |
| Marka | Arri |
| Dimensions (W x H x D) | 7.4 x 5.6 x 5.5" / 188 x 143 x 140 mm |
| Plate Rear Mount | Mounting Holes |
| Plate Material | Aluminum |
| Adapter Type | 19 to 15mm |
| Dimensions and Weight | Not specified by manufacturer |
| Rod Support | 1 x 19mm |
| Accessory Mounting Threads | 3/8"-16, 1/4"-20 |
| Adapter / Cable | Built-In Adapter • Input: LEMO 8-Pin Male • Cable: Length Unspecified |
Fiyat:
7.408.051,20 ₺
3500 TL üzeri alışverişlerde kargo bedava
