| General | |
|---|---|
| Dimensions | 10 x 9.6 x 3" / 254 x 243.8 x 76.2 mm (Folded) 14.6 x 7.5 x 7.4" / 370.8 x 190.5 x 188 mm |
| Weight | 2.34 lb / 1.06 kg |
| Operating Conditions | -4 to 113°F / -20 to 45°C |
| Materials | Aluminum Alloy |
| Inputs/Outputs | 3x USB-C (Control / Video) 1x USB-C (Power) |
| Gimbal Design | Single Handgrip (Slanted) |
| Accessory Mounting | 1 x 1/4"-20 Female 2 x NATO Rail |
| Packaging Info | |
| Package Weight | 4.51 lb |
| Box Dimensions (LxWxH) | 12.4 x 9 x 2.9" |
| Power | |
| Battery Runtime | 12 Hours |
| Battery Charging Time | 2.5 Hours |
| Compatibility | |
| Camera Control | On Compatible Models (See Full Compatibility List) |
| Gimbal | |
| Number of Axes | Three: Pitch (Tilt) / Roll / Yaw (Pan) |
| Rotation Range | Mechanical Range Yaw (Pan): 360°  Roll: 334° (-95 to 240°)  Pitch (Tilt): 326° (-112 to 214°)  |
| Follow Speed | Pan/Tilt/Roll: 360°/s |
| Specs | |
| Load Capacity | 6.6 lb / 3 kg |
| Battery Type | Built-In (3000 mAh) |
| Wireless | 2.4 GHz Radio/RF / Bluetooth 5.1 |
| Mobile App Compatible | Yes: Android & iOS App Name: Ronin App |
| Operating Voltage | 7.2 VDC |
| Monitor | |
| Display Type | Fixed Touchscreen OLED |
| Remote Controller / Transmitter | |
| Transmission System | Bluetooth 5.1 2.4 GHz |
| Transmitter I/O | 4 x USB-C (Power/Camera Control/Video Transmission/Focus Motor) 2 x NATO |
| Others | |
| Marka | DJI |
