| General | |
|---|---|
| Dimensions | 10 x 7.1 x 5.8" / 255 x 180 x 148 mm |
| Weight | 7.1 lb / 3.2 kg |
| Inputs/Outputs | 1x Block 4-Pin (Locking, Removable) |
| Active/Passive | Passive |
| Packaging Info | |
| Package Weight | 17.05 lb |
| Box Dimensions (LxWxH) | 16.5 x 13 x 10.2" |
| Specs | |
| Color | Black |
| Environmental Resistance | Dust/Water-Resistant (IP65) |
| Construction Material | ABS |
| Frequency Response | 55 Hz to 20 kHz -10 dB 90 Hz to 20 kHz -3 dB |
| Impedance | 8 Ohms (Nominal) 6.5 Ohms (Minimum) |
| LF Driver | 5.2" / 133 mm |
| Maximum SPL | 108 dB (Continuous) 114 dB (Peak) |
| HF Driver | 0.8" / 20 mm |
| Sensitivity | 89 dB |
| Coverage Angle | 90° H x 90° V |
| Others | |
| Marka | Electro Voice |
| Speaker Configuration | 2-Way |
| Constant Voltage / Transformer Taps | 100 V 60 / 30 / 15 W or 8 Ohms Bypass 70 V 60 / 30 / 15 / 7.5 W or 8 Ohms Bypass |
| Number of Included Speakers | 2 |
| Power Handling | For 100 Hours: 300 W Peak 75 W RMS |
| Maximum Wire Gauge | 12 AWG / 2.5 mm |
| Transformer Wattage | 60 W |
