| General | |
|---|---|
| Dimensions | 30.26 x 16.00 x 16.27" (768.6 x 406.3 x 413.3 mm) |
| Weight | 65.5 lb (29.7 kg) |
| Connectors | Dual 4-pin 10 AWG Phoenix/Euro Block screw-terminals CDG dual-gland-nut input panel cover plate (included) |
| Wireless | |
| Frequency Range | -10 dB: 66 Hz to 21 kHz |
| Specs | |
| Frequency Response | -3 dB: 118 Hz to 18 kHz |
| Impedance | 8 Ohms (nominal), 6 Ohms (minimum) LF Transducer - DVX3151A: 8 Ohms (nominal), 7.2 Ohms (minimal) HF Transducer - DH7N: 8 Ohms (nominal), 6 Ohms (minimal) |
| SPL | Maximum Calculated: 131 dB LF Transducer - DVX3121A: 131 dB HF Transducer - DH7N: 137 dB |
| Enclosure | 13-ply birch weather-resistant fiberglass finished (IP55-rated) |
| Coverage | Rotatable: 90° x 60° |
| Wireless Connectivity | |
| Frequency | Receiver High Pass: 65 Hz |
| Others | |
| Marka | Electro Voice |
| Power Handling | Passive: 600 W continuous, 2400 W peak LF Transducer - DVX3151A: 500 W continuous, 2000 W peak HF Transducer - DH7N: 75 W continuous, 300 W peak |
| Axial Sensitivity | 97 dB (1 W @ 3.28' / 1 m) LF Transducer - DVX3121A: 98 dB (1 W @ 3.28' / 1 m) HF Transducer - DH7N: 112 dB (1 W @ 3.28' / 1 m) |
| Grille | 18 GA stainless steel with hydrophobic cloth |
| Suspension | 22 x M10 threaded suspension points |
| Passive Crossover Frequency | 1300 Hz |
