| General | |
|---|---|
| Dimensions | 16.5 x 11.7 x 9" / 41.9 x 29.7 x 22.9 cm |
| Weight | 11.9 lb / 5.4 kg |
| Inputs/Outputs | Block |
| Active/Passive | Passive |
| Packaging Info | |
| Package Weight | 35 lb |
| Box Dimensions (LxWxH) | 21.3 x 18.2 x 15" |
| Wireless | |
| Frequency Range | 62 Hz to 20 kHz -10 dB |
| Specs | |
| Color | Black |
| Environmental Resistance | Dust/Water-Resistant (IP34) |
| Construction Material | ABS, Metal Grille |
| Impedance | 8 Ohms (Transformer Bypassed) |
| LF Driver | 2x 6" / 15.2 cm |
| Maximum SPL | 118 dB |
| HF Driver | 1" / 2.5 cm Titanium-Coated Direct-Radiator |
| Sensitivity | 94 dB |
| Coverage Angle | 100° H x 80° V |
| Others | |
| Marka | Electro Voice |
| Speaker Configuration | 2-Way |
| Constant Voltage / Transformer Taps | 100 V 15 / 30 / 60 W or 8 Ohms Bypass 70 V 7.5 / 15 / 30 / 60 W or 8 Ohms Bypass |
| Crossover | 1.6 kHz |
| Number of Included Speakers | 2 |
| Power Handling | 300 W Program 600 W Peak |
