| Connectivity | |
|---|---|
| USB | 1x USB-B (Host Connection, Multitrack Record) 1x USB-A (2-Track Record, Audio Playback, Control, External Memory) |
| Analog Outputs | 8x XLR 3-Pin Balanced Output |
| USB I/O Capacity | 18x Input / 18x Output |
| Expansion Ports | No |
| General | |
| Dimensions | 12.6 x 5.5 x 17.9" / 32 x 14 x 45.5 cm |
| Weight | 14.3 lb / 6.5 kg |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| Display | Main Display: 9" LCD Touchscreen |
| Noise Floor | -84 dBu A-Weighted |
| Packaging Info | |
| Package Weight | 20.215 lb |
| Box Dimensions (LxWxH) | 21.7 x 17.7 x 10.3" |
| Performance | |
| Headphone Output Power | 2.5 mW 100 mW (Max) |
| Max Input Level | Mic/Line Input: +24 dBu |
| I/O Impedance | Combo XLR-1/4", XLR Line/Mic Input: 10 Kilohms (Balanced/Unbalanced) XLR Output: 75 Ohms Headphone Output: 10 Ohms |
| Signal Generator | Yes |
| Control | |
| Presets | 200x Scene 13x Preset (Factory) |
| Mixer | |
| Max I/O Capacity | 20x Input / 12x Output |
| Number of Analog Output Channels | 8 |
| Mix Routing | 1x Stereo Main LRC 6x Bus 2x Mono Matrix 2x Stereo FX Return |
| Specs | |
| Number of Analog Input Channels | 16 (16 Mono / 1 Stereo) |
| Wireless | No |
| Number of Mic Preamps | 16 |
| Frequency Response | 20 Hz to 20 kHz +0.5/-1 dB |
| Rack Mountable | Yes |
| EQ | Input Channels, Output Buses, Outputs, Subgroups, FX Returns: 4-Band Parametric |
| Sample Rates | 48 kHz 96 kHz |
| MIDI I/O | No |
| Analog Inputs | 12x XLR 3-Pin Balanced Mic/Line Input 4x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input |
| Gain/Trim Range | 0 dB to +64 dB |
| Analog Dynamic Range | Output: 110 dB |
| THD | < 0.01% at Min Gain (+4 dBu) |
| File Format Support | Playback: MP3, WAV Record: MP3, WAV |
| Electrical | |
| Input Power | 24 VDC at 2.5 A 100 to 240 VAC, 50 / 60 Hz |
| Recording | |
| Max Multitrack Recording | 18 Tracks |
| Bit Depth | Record: 24 / 32-Bit |
| Software | |
| OS Compatibility | iPadOS Only |
| Interface | |
| Digital I/O | 2x etherCON Dante Input/Thru (I/O, Network) 1x RJ45 Ethernet (Network) |
| Signal Processing | |
| Built-In Effects | 18x Effect (Type Unspecified) |
| Input Pad | -24 dB |
| Dynamic Processing | Compressor, Gate |
| Input Polarity | Normal/Reverse |
| Graphic EQ | Yes |
| Audio Delay | Adjustable Up to 1000 ms |
| Diğer | |
| Marka | OEM |
| Faders & Level Adjustment | 9x 3.9" / 100 mm Motorized Fader(Touch Sensitive) |
Fiyat:
166.139,57 ₺
3500 TL üzeri alışverişlerde kargo bedava
