| General | |
|---|---|
| Dimensions | Fits AJA R-Series Rack Frames |
| Weight | Not Specified by manufacturer |
| Packaging Info | |
| Package Weight | 0.35 lb |
| Box Dimensions (LxWxH) | 13 x 9.65 x 3.15" |
| Power | |
| Power Source | 5 to 18 VDC from rack frame Power Supply |
| Specs | |
| Input | Digital HDTV: On a Looping 75 Ohm BNC connecter,1035i @ 50 to 60 Hz,1080i 50 to 60 Hz,1080p 24sf,1080p 25sf,720p @ 50 to 60 HzStandard SDI, SMPTE 259M, on BNC connector |
| Output | Digital HDTV:,On two looping 75 ohm BNC connecters,Standard Definition Digital:,SDI on a 75 ohm BNC connecter,Standard Definition Analog:,Three Composite NTSC/PAL on BNC Connecters or,One Y/C utilizing two BNC connecters or,One Component (YUV, RGB) on three BNC connectersStandard SDI x2, Loop Out, on BNC connectors |
| Control | External Dip Switch:,Input Video,Output Video,Gradicule 4:3 Overlay,Output Pedestal,Aspect Ratio Output |
| Conversion | Digital HDTV to Standard Definition SDI, YUV, RGB, Composite and Y/C Video |
| Diğer | |
| Marka | AJA |
Anlaşmalı tüm kredi kartlarında
| Taksit | Aylık Ödeme | Toplam Tutar |
|---|---|---|
| Tek Çekim | 34.033,25 ₺ | 34.033,25 ₺ |
| 2 Taksit | 17.742,28 ₺ | 35.484,57 ₺ |
| 3 Taksit | 12.087,82 ₺ | 36.263,45 ₺ |
| 6 Taksit | 6.538,57 ₺ | 39.231,41 ₺ |
| 9 Taksit | 4.808,59 ₺ | 43.277,28 ₺ |
| 12 Taksit | 4.083,08 ₺ | 48.996,90 ₺ |
Tutarlara KDV dahildir. Taksit seçenekleri kartınızın bankasına göre ödeme adımında kesinleşir.
