| General | |
|---|---|
| Dimensions | 5.8 x 4 x 1" (15 x 10 x 2.5 cm) |
| Packaging Info | |
| Package Weight | 1.55 lb |
| Box Dimensions (LxWxH) | 9.8 x 7.2 x 2.8" |
| Specs | |
| Input | 4x 4K/HD/SD-SDI (auto-selected) |
| Input Formats | 4x 1.5 GHz SDI:,3840 x 2160-p, 4:2:2, 23.98, 24, 25, 29.97, 30,3840 x 2160-psf, 4:2:2, 23.98, 24, 25, 29.97, 30,4096 x 2160-p, 4:2:2, 23.98, 24,4096 x 2160-psf, 4:2:2, 23.98, 24,2x dual-stream 3 GHz SDI (level B):,3840 x 2160-p, 4:2:2, 23.98, 24, 25, 29.97, 30,3840 x 2160-psf, 4:2:2, 23.98, 24, 25, 29.97, 30,4096 x 2160-p, 4:2:2, 23.98, 24,4096 x 2160-psf, 4:2:2, 23.98, 24,4x 3 GHz SDI:,3840 x 2160-p, 4:4:4, 23.98, 24, 25, 29.97, 30,3840 x 2160-psf, 4:4:4, 23.98, 24, 25, 29.97, 30,4096 x 2160-p, 4:4:4, 23.98, 24,4096 x 2160-psf, 4:4:4, 23.98, 24,HD inputs supported (4:2:2 if Single Link or 4:4:4 if Dual Link):,720p 23.98, 24, 25, 29.97, 30, 50, 59.94,1080i 25, 29.97, 30,1080p 23.98, 24, 25, 29.97, 50, 59.94, 60,1080psf 23.98, 24, 25, 29.97, 50, 59.94, 60,SD inputs supported:,525i, 625i |
| Power | 5-18 VDC regulated, 3 W, required power supply included |
| Output | 10-bit HDMI 1.4a,USB (for connection to Mac or PC) |
| HDCP | The Hi5-4K does not encode the HDMI output with HDCP encryption. By definition, HD-SDI inputs to the Hi5-4K are unencrypted. The HDMI specification requires HDMI monitors to support unencrypted inputs. |
| Interface | |
| Audio I/O | SDI audio input, 8-channel embedded,HDMI audio output, 8-channel embedded |
| Others | |
| Marka | AJA |
Fiyat:
17.463,91 ₺
3500 TL üzeri alışverişlerde kargo bedava
