AJA 3G-AMA 3G-SDI 4 Kanallı Analog Ses Embedder / Disembedder / 3G-AMA-R0

(0 değerlendirme)
48.646,00 ₺ 48.646,00 ₺ KDV dahil

  • Marka - AJA
  • Dimensions
  • Package Weight
  • Box Dimensions (LxWxH)
  • Input Formats
  • Embedded Audio
  • Video Output
  • Power
  • Output Formats
  • Audio I/O
  • Audio Converters
  • User Controls
  • Audio Latency
  • Audio Level Control
  • Environmental
  • Video Inputs
AJA
Bize Ulaşın
General
Dimensions 5.8 x 3.1 x 1" / 147 x 79 x 25 mm
Packaging Info
Package Weight 2.69 lb
Box Dimensions (LxWxH) 10.2 x 5.65 x 3.8"
Format Support
Embedded Audio SMPTE 272M (SD): 20-bit, 48 kHz synchronous,SMPTE 299M (3G/HD): 24-bit, 48 kHz synchronous,Incoming embedded audio can be passed, removed, or overridden.,Up to 16 channels supported.,NOTE: 2048x1080p/psf 29.97 and 30 formats support a maximum of 8 channels embedded audio.
Video Capture
Video Output 1 x SDI (BNC)
Specs
Input Formats 3G-SDI:,2048x1080p 23.98/24/25/29.97/30/50/59.94/60,2048x1080psf 23.98/24/25/29.97/30,1920x1080p 23.98/24/25/29.97/30/50/59.94/60,1920x1080psf 23.98/24/25/29.97/30,1920x1080i 25/29.97/30,1280x720p 50/59.94/60,HD-SDI:,2048x1080p 23.98/24/25/29.97/30,2048x1080psf 23.98/24/25/29.97/30,1920x1080p 23.98/24/25/29.97/30,1920x1080psf 23.98/24/25/29.97/30,1920x1080i 25/29.97/30,1280x720p 23.98/24/25/29.97/30/50/59.94/60,SD-SDI:,525i,625i
Power 5 to 20 VDC, 5 W
Output Formats Video Out is a delayed, reclocked version of Video In, at same frame rate, etc. Video Out is undefined when no input.,Video Latency:,SD-SDI - 17.2 µsec,HD-SDI - 6.3 µsec,3G-SDI level A - 3.2 µsec,3G-SDI level B - 6.1 µsec
Audio Converters 24-bit
User Controls External DIP switch,USB port for MiniConfig software application
Audio Latency Embed from audio input:,1100 µsec,Disembed from video input:,1200 µsec
Audio Level Control Settings Configured via MiniConfig Software:,Pro 1: 0 dBfs = +24 dBu,Pro 2: 0 dBfs = +18 dBu,Pro 3: 0 dBfs = +15 dBu,Consumer 1: 0 dBfs = +12 dBu
Environmental Operating Temperature: 32 to 104&degF / 0 to 40&degC,Operating Relative Humidity: 10-90% non-condensing,Operating Altitude: <8,000' / <2,500 m,Safe Storage Temperature (Power OFF): -40 to 140&degF / -40 to 60&degC
Input
Video Inputs 1 x SDI (BNC):,SD SMPTE 259M,HD SMPTE 292/296M,3G SMPTE 424/425M
Interface
Audio I/O 1 x DB-25 for 4 channels I/O,DB-25 Breakout cable:,4 x XLR female input breakout connectors,4 x XLR male output breakout connectors
Others
Marka AJA
