| Connectivity | |
|---|---|
| USB | No |
| General | |
| Weight | 105.8 lb / 48.0 kg |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Packaging Info | |
| Package Weight | 151 lb |
| Box Dimensions (LxWxH) | 28.5 x 25.5 x 23" |
| Power | |
| Power Consumption | 2 W (Standby) 20 W (Idle) 400 W (Maximum) |
| Performance | |
| Maximum Input Level | +24 dBu |
| Wireless | |
| Frequency Range | 19 Hz to 150 Hz (-6 dB) |
| Specs | |
| Color | Black |
| Monitor Type & Configuration | Active Subwoofer |
| Wireless | No |
| Total Power Output | 400 W |
| Network I/O | 2x RJ45 Ethernet |
| Digital Audio I/O | 1x XLR 3-Pin AES3 Input 1x XLR 3-Pin AES3 Output |
| Subwoofer Drivers | 1x 12" / 30.4 cm Cone |
| EQ | 1x LF Shelf: -12 to 0 dB at 20 Hz (4 dB Increments) |
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| Number of Included Monitors | Single Monitor |
| Enclosure | Bass-Reflex/Ported, Shielded |
| Subwoofer | 1x 12" / 30.4 cm Cone |
| Maximum Sound Pressure Level (SPL) | 118 dB |
| Filters | Low-Pass at 85 Hz High-Pass at 85 Hz |
| Phase Adjustment | 4-Position Switch |
| Total Harmonic Distortion (THD) | 0.01% |
| Analog Input Sensitivity/Gain | +48 dBu to -6 dBu (Continuously Variable) |
| Monitor Orientation | Vertical |
| Interface | |
| Audio I/O | 9x XLR 3-Pin Balanced Input 9x XLR 3-Pin Balanced Output |
| Others | |
| Marka | Genelec |
| Dimensions (W x H x D) | 21.9 x 24.6 x 19.5" / 555 x 625 x 496 mm |
| Self-Generated Noise | Less Than 5 dBA (at 3.28' / 1 m) |
